Flow Coupling
● Mechanical property as per API 5CT, 5B and Customer requirements.
● Heavy wall thickness pipe in high-quality alloy steel to ensure maximum abrasion resistance and strength.
● Length could be made in 6ft, 8ft, 10ft, 20ft, and customer's requirements.
Description
China Vigor Drilling Oil Tools And Equipment Co., Ltd. is one of the most professional manufacturers and suppliers of flow coupling in China, featured by competitive price and fast delivery. Welcome to buy high quality flow coupling in stock here from our factory.
The flow coupling is a thickened pipe, its inner diameter is the same as the inner diameter of the oil pipe, but its outer diameter is slightly larger, the O.D. of the heavy wall pipe is the same as the tubing coupling diameter. it is typically located just above and below flow control equipment where turbulent flow problems are likely to occur, such as small-diameter nipple profiles, expansion joints, safety valves, gauges, and gas lift mandrels. It is used in high-yield oil and gas wells, and oil wells with average output can choose to use it or not. When the high-yield oil and gas flow flows through the safety valve, it will have a throttling effect due to diameter reduction, causing eddy current erosion and wear at its upper and lower ends.
Working Principle
Flow coupling works by reducing turbulence and erosion caused by the flow of fluids through restricted areas. The couplings feature a thicker wall and internal beveled transitions that create a smoother flow path, minimizing the formation of turbulent eddies and vortices that can lead to accelerated wear and erosion of the tubing and completion equipment.
Features and Application
Features
- Compliant with API 5CT and other industry standards
- Available in various thread types (BTC, LTC, STC) and sizes (2 3/8" to 7" O.D.)
- Customizable lengths, material grades, and threading options
- Suitable for standard service, H2S environments, and HP/HT conditions
- Manufactured from seamless mechanical tubing
Application
Vigor Drilling Blast Joint and Flow coupling are placed as part of the tubing string in front of perforations.
- Upstream and downstream of flow control equipment
- Above and below small-diameter nipple profiles
- Near expansion joints and safety valves
- In locations prone to turbulent flow and erosion
Technical Parameters
| Tubing | O.D.(In.) | I.D.(In.) | Grade | |
| Size(In.) | Weight(lb/ft) | |||
| 2-3/8" | 4.60 | 2.707 | 1.995 |
AISI 4130/4140 to meet API Grades -J55,K55,N80,L80,C90,T95,P110, also available in 9Cr 80,13Cr 80/85,13Cr95,Super 13 Cr95. |
| 2-3/8" | 4.70 | 3.063 | 1.995 | |
| 2-7/8" | 6.40 | 3.240 | 2.441 | |
| 2-7/8" | 6.50 | 3.668 | 2.441 | |
| 3-1/2" | 9.20 | 3.900 | 2.992 | |
| 3-1/2" | 9.30 | 4.500 | 2.992 | |
| 4-1/2" | 12.60 | 4.892 | 3.958 | |
| 4-1/2" | 12.80 | 5.563 | 3.958 | |
| 5-1/2" | 17.00 | 6.050 | 4.892 | |
| 7" | 26.00 | 7.658 | 6.184 | |
Material
It is made from high-quality alloy steel to ensure maximum abrasion resistance and strength.
The material grade also could be AISI 4130/4140 to meet API Grades -J55, K55, N80, L80, C90, T95, P110, also available in 9Cr 80,13Cr 80/85,13Cr95, Super 13 Cr95, standard as per API 5CT.
In H2S service, the hardness is available to be heat-treated to between 18 and 22 HRC as per NACE MR-0175.
Threads are available in API tubing connections.
Most tubing connections can be supplied, however, I.D./O.D. dimensions may vary depending on the tubing connection and tubing weight.
Advantages
● Extends the life of production tubing and completion equipment
● Minimizes internal and external erosion caused by turbulent flow
● Connection and body performance match or exceed production tubing standards
● Cost-effective solution for reducing turbulence-related wear
Ordering Information
Flow couplings are available in various sizes, weights, and material specifications to meet diverse project requirements. Customers can request specific lengths, grades, and threading options to suit their needs. Standard lengths include 3", 6", 8", 10", and 20".
Vigor is a professional manufacturer and supplier, offering a large inventory, prompt delivery, and secure packaging to ensure product integrity. If you are looking for competitive, high-quality, and fast-delivery oilfield flow coupling in stock or API from one of the leading blast joint coupling manufacturers and suppliers in China, please feel free to contact VIGOR, Their team of experts is dedicated to providing exceptional service and support to global customers and distributors in the oil and gas industry.
